• High precision X/Y/Z-axis CNC fully auto control, high position accuracy;
  • “00” grade “JINANQING”marble base and pillar, stable and reliable;
  • Precision linear guide, grinding ball screw and AC servo motor, ensure accuracy stability of system position;
  • 0.5um high precision linear scale, ensure position and measurement accuracy;
  • Imported high definition color industry digital camera, ensure clear observation and stable measurement requirement;
  • 6.5X click zoom lens, precision manual zoom, only need to make pixel calibration once time;
  • Programmable 5-ring 8-division LED surface illumination, contour parallel LED illumination, can realize 256 grade brightness adjustment intelligently;
  • With proprietary powerful function fully auto measuring software iMeasuring 4.1;
  • Can set auto measurement, and finish batch measurement with high efficient;
  • Laser, probe, coaxial illumination and other parts are optional;
  • Optional FexQMS Measuring Data Analysis and Real-time monitoring software which enhance program control and reduce material consumption.
