FEATURES
Operating and display unit
• Large and clearly defined touch display with backlighting
• Operator guidance with self explanatory icons
• Multilingual user guidance
• Option of setting additional zero points on the workpiece
• Additional measuring instrument can be connected via MarConnect USB port
• Future-proof thanks to software updates
• Automatic activation of standby mode
• Selectable auto-off function, without loss of measured values

Functions
• Top or bottom contacting
• Web width or distances between grooves, including center of web or groove
• Bore or shaft diameter, including center of bore or shaft
• Bore reversing point (up or down)
• Shaft reversing point (up or down)
• Calculating distances or symmetry
• Dynamic measuring functions
• Perpendicularity measurement
• Straightness measurement
• Measurement in 2D mode
• Measuring programs
• Measuring data processing Measuring system
• Optical incremental measuring system for outstanding measuring accuracy and reliability
• Dynamic probe system enabling high repeatability
• Air bearing system for light and smooth movement
• Motorized measuring slide simplifies measurement runs
• Probe constant remains after the instrument is switched off
• Integrated rechargeable battery with a long operating life for mains-independent measurement
• Temperature compensation via internal temperature sensor

Scope of delivery
• Height measuring instrument incl. operating and display element
• Carrier 817 h1
• Measuring anvil K6/51
• Setting gage 817 eb
• USB cable
• Operating instructions
• Recharging unit
• Protective cover
• Calibration certificate
